Additional information
| Weight | 0.6218 kg |
|---|---|
| Rated insulation voltage (Ui) VAC | 1500V |
| Rated thermal current (Ith) A | 32A |
| Rated impulse without voltage (Uimp) | 8000V |
| Rated short-time with stand current (Icw) 2,4,6,8 | 1000A |
| Rated short-time with stand current (Icw) 2H, 3H, 4H | 1700A |
| Rated short-time making capacity (Icm) 2,4,6,8 | 1000A |
| Rated short-time making capacity (Icm) 2H, 3H, 4H | 1700A |
| Rated conditional short circuit current (lcc) | 5000A |
| Maximum Fuse Size (gL(gG) | 80A |
| Part Number | DE1S.04.32DC |
